10 MHz External clock.

Clock Core: High-performance OCXO
Phase Noise:
–115 dBc @1Hz Offset (Guaranteed)
–140 dBc @10Hz Offset (Guaranteed)
Thermal Design: Independent thermos cabinet
Power Transformer: 30VA toroidal transformer
Regulation Topology: Two-stage linear regulation (LM350T + LT3041)
Clock Distribution: Ultra-low additive phase noise amplifier
Grounding: Dedicated ground terminal with selectable ground switch
Indicators: OCXO warm-up LED, Power LED

Q&A:

Q: What is the difference between OCK-2S and OCK-2P?

A:Both are 10 MHz OCXO master clocks. OCK-2P is an upgraded version of OCK-2S, offering:

• A higher-precision OCXO with lower phase noise (< -115 dBc vs. < -110 dBc)
• Improved internal circuit and power supply design
• Enhanced chassis and internal isolation structure

OCK-2P focuses on further refinement in stability, detail, and timing accuracy, while OCK-2S already delivers excellent core performance.

Q: What is the purpose of the Float / Ground switch?
A: If multiple devices are grounded, a ground loop can occur and cause hum or noise. Switching one device to Float breaks the loop and helps reduce or eliminate the noise.

Dimensions: 240 x 175 x 50 (mm)

Weight: 2.2Kg

1 Year Warranty.

Order need 2-4 days.
